2
NAME OF PARTS
Fig. 2 Outdoor Unit
Outlet port
Drain pipe
(Safety)
Intake port
Drain pipe
(Main)
Outlet port
Intake port
Electrical Breaker
The breaker is installed during the electrical installation.
Fig. 3 Remote controller
1 Start/Stop Button
2 Set Temperature Button
3 Master Control Button
4 Fan Control Button
5 THERMO SENSOR Button
6 ENERGY SAVE Button
7 Timer Mode (CLOCK ADJUST)
Button
8 DAY (DAY OFF) Button
9 SET BACK Button
0 Set Time Button
A DELETE Button
DAY OFF
DELETE SET
ENERGY
SAVE
THERMO
SENSOR
SET BACK
DAY
CLOCK ADJUST
SU MO TU WE TH FR SA
369 12 15 18 21
D
2
7
8
9
0
A
B
G
F
E
H
I
C
1
3
4
5
6
B SET Button
C Operation Lamp
D Timer and Clock Display
E Operation Mode Display
F Fan Speed Display
G Operation Lock Display
H Temperature Display
I Function Display
Defrost Display
Thermo Sensor Display
Energy Save Display
Fig. 1 Indoor Unit
