4-6. Pressure switch
¢ Models: AOHG36KRTA, AOHG45KRTA, and AOHG54KRTA
• Type of contact
C
H
Pressure
• Characteristics of pressure switch
Pressure switch 1
Contact: Short → Open 4.2 — 4.05 MPa
Contact: Open → Short 3.2 ± 0.15 MPa
36/45/54 model: P770
4-6. Pressure switch - (03-65) - 4. Service parts information
