Item no. Part no. Part name Service part
1 9383880001 Top panel assy ♦
2 9383779008 Protective net ♦
3 9375361013 Net rubber ♦
4 9900984038 Thermistor (Heat exchanger) ♦
5 9900727154 Thermistor assy ♦
6 9383607004 Thermo holder ♦
7 9383874000 Right panel sub assy ♦
8 9383879005 Rear pipe cover ♦
9 9709684139 Inverter PCB ♦
10 9900634025 Reactor assy ♦
11 9901053016 Terminal ♦
12 9711431318 Main PCB (Service) ♦
13 313166024302 Drain cap ♦
14 9303029015 Drain assy ♦
15 9350255009 Base assy (Service) ♦
16 9383876004 Service panel sub assy ♦
17 9383878008 Front pipe cover ♦
18 9372171059 Emblem rear ♦
19 9383863004 Front panel assy ♦
20 9383604003 Blow grille ♦
21 9383689000 Blow grille insulation ♦
22 9383882005 Left panel sub assy ♦
23 9383336003 Propeller fan ♦
24 9603732011 Brushless motor ♦
25 9383862007 Motor bracket assy ♦
26 9374420612 Condenser sub assy ♦
a — Separate wall assy —
b — Control box unit —
4-1. Model: AOHG36KRTA - (02-19) - 4. Outdoor unit parts list
