Item no. Part no. Part name Service part
50 9383858017 Sound insulation unit
51 9900565091 Thermistor (Outdoor temp.)
52 9900186029 Pressure switch
53 9374425624 4-way valve assy
54 9970194016 Solenoid
55 9970158018 Sensor
56 9384848000 Accumulator assy (Service)
57 9970209000 Expansion valve coil
58 9370947311 Expansion valve assy
59 9379079013 3-way valve assy
60 9377958037 3-way valve assy
61 9900985028 Thermistor (Compressor)
62 9379179089 Rubber washer F
63 9383851131 Compressor unit
a Thermistor spring
b Joint pipe D
c Wiring fixation unit
4-2. Models: AOHG45KRTA and AOHG54KRTA - (02-25) - 4. Outdoor unit parts list
