Slim duct type
Model: ARXG18KLLAP
Part name Exterior Q’ty Part name Exterior Q’ty
Operating manual 1 Filter (large) 2
Operating manual
(CD-ROM)
1 Drain hose 1
Installation manual 1 Hose band 1
Installation template 1 Drain hose insulation B 1
Washer 8
Insulation
(for electrical wiring)
2
Cable tie (large) 4
Coupler heat insulation
(large)
1
Cable tie (medium) 3
Coupler heat insulation
(small)
1
5-1. Indoor unit - (02-27) - 5. Accessories
