3. OUTLINE AND DIMENSIONS
– 30 –
3.1 MODELS : AS ✽ 7A, 7R
3.1.1 INDOOR UNIT
3.1.2 OUTDOOR UNIT
790 (31-3/32")
808 (31-13/16")
170 (6-11/16")
150 (5-29/32")
248 (9-25/32")
650 (25-19/32")
250 (9-27/32")
535 (21-1/16")
Unit : mm (inch)
