6. OUTDOOR FAN CONTROL
Cooling Dry Heating
AS*A09LKC
AS*A12LKC
730/ 650/ 470
860/ 760/ 470
860/ 470/ 330
730/ 470/ 230
( Table 8 : Outdoor fan speed )
*
The outdoor fan speed mentioned avobe depends on the compressor frequency.
(When the compressor frequency increases, the outdoor fan speed also changes to the higher
speed. When the compressor frequescy decreases, the outdoor fan speed also changes to the
lower speed.)
*
It runs at 500(A-D ZONE)rpm for 20 seconds after starting up the outdoor fan.
*
After the defrost control is operated on the heating mode, the fan speed keeps at the higher speed
as table 9 without relating to the compressor frequency.
01-07
A - C
D
A - C
D
ZONE
730/ 470
760/ 470
650/ 470
760/ 680/ 470
Refer to Fig1.
(rpm)
( Table 9 : Outdoor fan speed after the defrost )
1. Outdoor Fan Motor
2. Fan Speed
AC Motor DC Motor
AS*A09/ 12LKC
Following table shows the type of the outdoor fan motor. The control method is different
between AC motor and DC motor.
( Table 7 : Type of Motor )
Min
AS*A09/ 12LKC 900rpm
To Next Page
