Test 2 : Check external cause at Indoor and Outdoor (Voltage drop or Noise)
Test 1 : Check indoor and outdoor installation condition
Test 3 : Check Wired Remote Controller and Controller PCB
OK
OK
Indoor Unit - Check incorrect wiring between Indoor Unit - Remote Control.
Or, check if there is an open cable connection.
Are these Indoor unit, Outdoor unit, and Remote control suitable model numbers to connect?
>> If there is some abnormal condition, correct it by referring to Installation manual and
Data & Technical Manual.
Turn off Power and check/ correct followings.
Is there loose or removed communication line of Indoor unit and Outdoor unit?
Instant drop ----- Check if there is a large load electric apparatus in the same circuit.
Momentary power failure ----- Check if there is a defective contact or leak current in the power supply circuit.
Noise ----- Check if there is any equipment causing harmonic wave near electric line.
(Neon bulb or electric equipment that may cause harmonic wave)
Check the complete insulation of grounding.
>> If it is DC12V, Remote Control is failure. (Controller PCB is normal) >> Replace Remote Control
>> If it is DC 0V, Controller PCB is failure. (Check Remote Control once again)
>> Check Indoor unit fan motor. (SERVICE PARTS INFORMATION 5)
If it is normal, replace Controller PCB.
If it is abnormal, replace Indoor unit fan motor and Controller PCB.
>> If the symptom does not change by above Check 1, 2, 3, replace Main PCB of Outdoor unit.
(SERVICE PARTS INFORMATION 10)
Check Voltage at terminal 1-3 of Controller PCB or Communication PCB.
(Power supply to Remote Control)
Compact Cassette, Slim Duct, Universal Floor, Ceiling Type : CN14
Wall Mount : CN16
Compact Wall Mount Type : CNC01(UTY-TWBXF)
OK
Trouble shooting 40
No Operation (Power is ON)
Forecast of Cause :
1. Setting / Connection failure.
2. External cause.
3. Electrical components defective.
02-55
>> If the symptom does not change by above Check 1, 2, 3, replace Main PCB of Outdoor unit.
>> If it is DC12V, Remote Control is failure. (Controller PCB is normal) >> Replace Remote Control
>> If it is DC 0V, Controller PCB is failure. (Check Remote Control once again)
>> Check Indoor unit fan motor. (PARTS INFORMATION 4)
I
If it does not operate properly after Remote Control exchange, replace Controller PCB
f it is normal, replace Controller PCB.
If it is abnormal, replace Indoor unit fan motor and Controller PCB.
For AR* G07/09/12/14/18LSLAP
(Power supply to Remote control)
Check Voltage at CN300 (terminal 1-3) of Controller PCB.(3 wire remote controller)
Check Voltage at CN300 (terminal 1-2) of Controller PCB.(2 wire remote controller)
2-3 TROUBLE SHOOTING WITH NO ERROR CODE
To Next Page
