PARTS
2
1
3
6
8
9
7
4
5
INDOOR UNIT
2012.12.25 15
5
2
6
4
3
Under Cover 9318879001
1 Bracket Panel 9318913002
8
Wire Cover 9318911008
9
Wire Shield 9318919004
7 Air Clean Filter Assy 9317250009
Remote Control 9319634012
Remote Control Holder
9318912005
Ref. Description Part number
Louver (Upper) 9318880007
Louver (Lower) 9318881004
