En-4
Fig. 6 Remote Control Unit
J SLEEP button
K MASTER CONTROL button
L SET TEMP. button (
/ )
M COIL DRY button
N Signal Transmitter
O TIMER MODE button
P TIMER SET ( / ) button
Q FAN CONTROL button
R START/STOP button
S SET button (Vertical)
T SET button (Horizontal)
U SWING button
V RESET button
W TEST RUN button
● This button is used when installing the
conditioner, and should not be used under
normal conditions, as it will cause the air
conditioner’s thermostat function to operate
incorrectly.
● If this button is pressed during normal opera-
tion, the unit will switch to test operation mode,
and the Indoor Unit’s OPERATION Indicator
Lamp and TIMER Indicator Lamp will begin
to fl ash simultaneously.
● To stop the test operation mode, press the
START/STOP button to stop the air condi-
tioner.
X CLOCK ADJUST button
Y 10°C HEAT button
Z Remote Control Unit Display (Fig. 7)
[ Transmit Indicator
\ Clock Display
] Operating Mode Display
` T imer Mode Display
a Fan Speed Display
b Temperature SET Display
c COIL DRY Display
d SLEEP Display
e SWING Display
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
●
When kept on pressing the MANUAL AUTO
button for more than 10 seconds, the forced
cooling operation will start.
● The forced cooling operation is used at the
time of installation.
Only for authorized service personnel’s
use.
● When the forced cooling operation starts by
any chance, press the START/STOP button
to stop the operation.
3 Indicator (Fig. 3)
4 Remote Control Signal Receiver
5 OPERATION Indicator Lamp (red)
6 TIMER Indicator Lamp (green)
●
If the TIMER indicator lamp fl ashes when the
timer is operating, it indicates that a fault has
occurred with the timer setting (See Page 14
Auto Restart).
7 COIL DRY Indicator Lamp (orange)
8 Intake Grille (Fig. 4)
9 Front Panel
0 Air Filter
A Air Flow Direction Louver
B Power Diffuser
C Right-Left Louver
(behind Air Flow Direction Louver)
D Drain Hose
E Air Cleaning Filter
Fig. 5 Outdoor Unit
F Intake Port
G Outlet Port
H Pipe Unit
I Drain port (bottom)
