12
● The range of swing is relative to the currently set airflow
direction.
● Although the indoor unit may beep, the swing range can-
not be changed during the SWING Operation using the
Remote Control Unit’s AIR FLOW DIRECTION button.
SWING OPERATION
Begin air conditioner operation before performing this procedure.
To select SWING Operation
Press the SWING LOUVER button (Fig. 6 P).
The SWING indicator lamp (orange) (Fig. 3 7) will light.
In this mode, the Air Flow Direction Louvers will swing automatically to direct the
airflow both up and down.
To Stop SWING Operation
Press the SWING LOUVER button (Fig. 6 P) once again.
The SWING indicator lamp (orange) (Fig. 3 7) will go out.
Airflow direction will return to the setting before swing was begun.
About Swing Operation
● During Cooling/Dry modes, if SWING Operation is con-
tinued at the lowest (downward) range for more than 30
minutes, the unit will automatically switch the swing range
to the horizontal flow range to prevent the condensation
of moisture on the outlet.
● The SWING operation may stop temporarily when the air
conditioner’s fan is not operating, or when operating at
very low speeds.
MANUAL AUTO OPERATION
Use the MANUAL AUTO operation in the event the Remote Control Unit is lost or otherwise unavailable.
How To Use the Main Unit Controls
Press the MANUAL AUTO button (Fig. 2 2) on the main unit
control panel.
To stop operation, press the MANUAL AUTO button once again.
(Controls are located inside the intake grille.)
● When the air conditioner is operated
with the controls on the Main unit, it
will operate under the same mode as
the AUTO mode selected on the Re-
mote Control Unit (see page 7).
● The fan speed selected will be “AUTO”
and the thermostat setting will be
standard.
9374666010_OM_en.p65 1/4/05, 3:27 PM12
