4
Fig. 6 Remote Control Unit
H SLEEP button
I MASTER CONTROL button
J SET TEMP./SET TIME buttons (
)
K Signal Transmitter
L TIMER button
M FAN CONTROL button
N START/STOP button
O AIR FLOW DIRECTION button
P SWING LOUVER button
Rear side (Fig. 7)
Q TIME ADJUST button
R ACL button
(located inside battery compartment)
S TEST RUN button
● This button is used when installing the
conditioner, and should not be used un-
der normal conditions, as it will cause the
air conditioner’s thermostat function to op-
erate incorrectly.
● If this button is pressed during normal op-
eration, the unit will switch to test opera-
tion mode, and the Indoor Unit’s OPERA-
TION Indicator Lamp and TIMER Indicator
Lamp will begin to flash simultaneously.
● To stop the test operation mode, either
press the TEST RUN button once again, or
press the START/STOP button to stop the
air conditioner.
T Remote Control Unit Display (Fig. 8)
U Transmit Indicator
V Clock Display
W Operating Mode Display
X T imer Mode Display
Y Fan Speed Display
Z Temperature Set Display
[ T imer Set Indicator
\ Temperature Set Indicator
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
3 Remote Control Signal Receiver
4 Indicator Lamps (Fig. 3)
5 OPERATION Indicator Lamp (red)
●
Lights when unit is operating.
*
● The lamp will flash slowly when the de-
frosting operation (See page 15).
6 TIMER Indicator Lamp (green)
● If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See Page 16 Auto Restart).
7 SWING Indicator Lamp (orange)
8 Intake Grille (Fig. 4)
9 Air Filter
0 Air Flow Direction Louver
A Right-Left Louver
(behind Air Flow Direction Louver)
B Drain Hose
C Air Cleaning Filter (optional)
Fig. 5 Outdoor Unit
D Intake Port
E Outlet Port
F Pipe Unit
9374666010_OM_en.p65 1/4/05, 3:27 PM4
