CN201
07 JB20 / PAP
1061 L=230
5V
C201
0.1
<F>
5V
+ C202
47/
10V
R201
47
<1/4W>
I C201
GP1UM261RKVF
5V
D201
SLR-325VC
D203
SLR-325DC
D202
SLR-325MC
5
4
6
1
2
3
7
2
1
3
VCC
OUT
GND
RED
GREEN
ORANGE
INDOOR UNIT
INDICATOR PCB ASSEMBLY
K05CY-0500HSE-D0
2009.09.10 7
