En-4
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
●
When kept on pressing the MANUAL
AUTO button for more than 10 seconds,
the forced cooling operation will start.
● The forced cooling operation is used at the
time of installation.
Only for authorized service personnel's
use.
● When the forced cooling operation starts
by any chance, press the START/STOP but-
ton to stop the operation.
● Please press the button at FILTER INDICA-
TOR RESET.
3 Indicator (Fig. 3)
4 Remote Control Signal Receiver
5 OPERATION Indicator Lamp (green)
6 TIMER Indicator Lamp (orange)
●
If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See Page 16 Auto Restart).
7 ECONOMY Indicator Lamp (green)
8 DEFROST Indicator Lamp (green)
9 Intake Grille (Fig. 4)
0 Front Panel
A Air Filter
B Airflow Direction Louver
C Right-Left Louver
(behind Airflow Direction Louver)
D Drain Hose
E Air Cleaning Filter
F Remote Controller (Wired/Option)
NAME OF PARTS
Fig. 5 Remote Controller
G Signal Transmitter
H MODE button
I 10°C HEAT button
J SET TEMP. button (
/ )
K ECONOMY button
L SLEEP button
M TIMER MODE button
N FAN button
O START/STOP button
P SET button
Q SWING button
R TIMER SET (
/ ) button
S CLOCK ADJUST button
T TEST RUN button
● This button is used when installing the air
conditioner, and should not be used un-
der normal conditions, as it will cause the
indoor unit’s thermostat function to oper-
ate incorrectly.
● If this button is pressed during normal op-
eration, the indoor unit will switch to test
operation mode, and the Indoor Unit’s OP-
ERATION Indicator Lamp and TIMER
Indicator Lamp will begin to flash simulta-
neously.
● To stop the test operation mode, press the
START/STOP button to stop the air
conditioner.
U RESET button
V Remote Controller Display (Fig. 6)
W Transmit Indicator
X Fan Speed Display
Y SWING Display
Z Timer Mode Display
[ Clock Display
\ Temperature SET Display
] Operation Mode Display
^ SLEEP TIMER Display
