02 - 12
)
-
OUTDOOR UNIT
AOTG09-12KMCA
OUTDOOR UNIT
AOTG09-12KMCA
SAFETY DEVICES10.
Protection form
Model
AOTG09KMCA AOTG12KMCA
Circuit protection
Current fuse
(Near the terminal)
――
Current fuse
(Main PC board)
250 V 20 A
250 V 5 A
Fan motor protection Thermal protection program
OFF: 150 ± 15 °C
ON: 120 ± 15 °C
Compressor protection
Thermal protection program
(Discharge temp.)
OFF: 110 °C
ON: After 2min. 20sec.
Thermal protection
Thermal protection fuse
(Terminal)
1 A 70 °C
