4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and the
indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢ Model: ASTG09KMTC
AFR
m
3
/h
700
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 2.26 2.12 0.22 2.52 2.33 0.26 2.79 2.48 0.30 2.92 2.52 0.31 3.02 2.58 0.28 3.22 2.63 0.31 3.38 2.68 0.30
0 2.41 2.31 0.36 2.61 2.40 0.37 2.75 2.45 0.35 2.88 2.52 0.36 2.95 2.55 0.36 3.19 2.63 0.36 3.42 2.70 0.37
5 2.39 2.30 0.20 2.59 2.38 0.21 2.72 2.43 0.20 2.86 2.50 0.20 2.92 2.53 0.21 3.17 2.62 0.20 3.39 2.69 0.21
10 2.36 2.27 0.26 2.55 2.37 0.28 2.69 2.42 0.25 2.82 2.48 0.26 2.89 2.52 0.27 3.13 2.59 0.26 3.35 2.67 0.27
15 2.32 2.25 0.32 2.51 2.34 0.33 2.64 2.39 0.32 2.77 2.45 0.32 2.84 2.49 0.32 3.07 2.57 0.32 3.29 2.63 0.33
20 2.27 2.22 0.37 2.45 2.31 0.39 2.58 2.35 0.37 2.71 2.42 0.38 2.77 2.45 0.39 3.00 2.53 0.38 3.22 2.60 0.39
25 2.20 2.18 0.43 2.38 2.27 0.45 2.51 2.31 0.42 2.63 2.38 0.43 2.70 2.41 0.43 2.92 2.48 0.43 3.12 2.55 0.44
30 2.13 2.13 0.47 2.30 2.22 0.50 2.42 2.26 0.47 2.54 2.33 0.47 2.60 2.36 0.49 2.81 2.43 0.47 3.02 2.49 0.50
35 2.04 2.04 0.52 2.21 2.16 0.54 2.32 2.20 0.52 2.44 2.27 0.52 2.50 2.30 0.53 2.70 2.37 0.52 2.89 2.43 0.54
40 1.94 1.94 0.56 2.11 2.10 0.59 2.21 2.14 0.56 2.32 2.20 0.56 2.38 2.22 0.58 2.57 2.30 0.56 2.76 2.36 0.59
46 1.79 1.79 0.63 1.92 1.92 0.61 2.02 2.02 0.63 2.08 2.08 0.61 2.12 2.12 0.62 2.27 2.27 0.63 2.43 2.30 0.63
¢ Model: ASTG12KMTC
AFR
m
3
/h
700
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 3.16 2.63 0.37 3.53 2.88 0.44 3.91 3.07 0.51 4.09 3.12 0.52 4.23 3.20 0.46 4.51 3.25 0.52 4.73 3.33 0.51
0 3.38 2.86 0.60 3.65 2.97 0.62 3.85 3.04 0.59 4.03 3.12 0.60 4.13 3.16 0.61 4.47 3.26 0.60 4.79 3.35 0.62
5 3.35 2.85 0.34 3.62 2.95 0.35 3.81 3.02 0.34 4.00 3.10 0.34 4.09 3.14 0.35 4.43 3.24 0.34 4.75 3.34 0.35
10 3.31 2.82 0.44 3.57 2.93 0.46 3.77 3.00 0.43 3.95 3.08 0.44 4.04 3.12 0.45 4.38 3.21 0.44 4.69 3.31 0.45
15 3.24 2.79 0.53 3.51 2.90 0.55 3.69 2.96 0.53 3.88 3.04 0.54 3.97 3.09 0.54 4.30 3.18 0.54 4.61 3.26 0.55
20 3.17 2.75 0.62 3.43 2.86 0.66 3.61 2.91 0.62 3.80 3.00 0.64 3.88 3.04 0.65 4.21 3.13 0.64 4.50 3.22 0.65
25 3.08 2.70 0.72 3.34 2.81 0.75 3.51 2.86 0.71 3.68 2.94 0.72 3.78 2.98 0.73 4.08 3.08 0.72 4.37 3.16 0.74
30 2.98 2.64 0.80 3.22 2.75 0.83 3.39 2.80 0.79 3.56 2.88 0.80 3.64 2.92 0.82 3.94 3.01 0.80 4.23 3.09 0.83
35 2.86 2.57 0.88 3.09 2.67 0.91 3.25 2.73 0.87 3.42 2.81 0.88 3.50 2.85 0.89 3.79 2.93 0.88 4.05 3.02 0.91
40 2.72 2.50 0.95 2.95 2.60 0.99 3.10 2.65 0.94 3.25 2.73 0.95 3.33 2.76 0.97 3.60 2.85 0.95 3.86 2.92 0.98
46 2.51 2.49 1.05 2.68 2.60 1.02 2.83 2.69 1.05 2.92 2.72 1.02 2.97 2.68 1.04 3.17 2.82 1.06 3.40 2.85 1.06
- 6 -
4-1. Cooling capacity 4. Capacity table
WALL MOUNTED ASTG09-12KMTC WALL MOUNTED ASTG09-12KMTC
