Fujitsu ASTG22LVCC - 6. CAPACITY TABLE

-
(
01 - 08
)
-
WALL MOUNTED TYPE ASTG09-22LV WALL MOUNTED TYPE ASTG09-22LV
CAPACITY TABLE6.
COOLING CAPACITY6-1.
MODEL

:ASTG09LV
MODEL

:ASTG12LV
MODEL

: ASTG18LV
MODEL

: ASTG22LV
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
IP : Input Power (kW)
AFR 13.2
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 2.32 1.59 0.37 2.59 1.60 0.38 2.68 1.74 0.38 2.85 1.74 0.38 2.94 1.88 0.39 3.12 1.87 0.39 3.29 2.00 0.39
25 2.22 1.52 0.43 2.47 1.52 0.44 2.55 1.66 0.44 2.72 1.66 0.45 2.80 1.80 0.45 2.97 1.79 0.45 3.14 1.90 0.46
30 2.10 1.43 0.50 2.34 1.44 0.51 2.41 1.57 0.51 2.57 1.57 0.51 2.65 1.70 0.52 2.81 1.69 0.52 2.97 1.80 0.53
35 1.98 1.35 0.56 2.20 1.36 0.57 2.28 1.48 0.57 2.43 1.48 0.58 2.50 1.60 0.58 2.65 1.59 0.59 2.80 1.70 0.59
40 1.73 1.18 0.56 1.93 1.19 0.57 1.99 1.29 0.57 2.12 1.30 0.57 2.19 1.40 0.58 2.32 1.39 0.58 2.45 1.49 0.59
43 1.61 1.10 0.55 1.80 1.11 0.56 1.86 1.21 0.56 1.98 1.21 0.57 2.04 1.31 0.57 2.17 1.30 0.58 2.29 1.39 0.58
AFR 13.5
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 3.26 2.29 0.61 3.64 2.31 0.62 3.76 2.51 0.62 4.01 2.51 0.63 4.13 2.72 0.63 4.38 2.70 0.64 4.63 2.88 0.64
25 3.11 2.19 0.70 3.47 2.20 0.71 3.59 2.39 0.71 3.82 2.40 0.72 3.94 2.59 0.73 4.18 2.58 0.73 4.42 2.75 0.74
30 2.95 2.07 0.79 3.28 2.08 0.81 3.39 2.26 0.81 3.62 2.27 0.82 3.73 2.45 0.82 3.95 2.44 0.83 4.18 2.60 0.84
35 2.77 1.94 0.89 3.08 1.95 0.90 3.19 2.12 0.91 3.40 2.13 0.92 3.50 2.30 0.92 3.71 2.29 0.93 3.92 2.44 0.94
40 2.45 1.72 0.88 2.72 1.73 0.90 2.82 1.88 0.90 3.00 1.88 0.91 3.10 2.03 0.92 3.28 2.03 0.93 3.47 2.16 0.93
43 2.25 1.58 0.89 2.51 1.59 0.90 2.59 1.73 0.90 2.76 1.73 0.91 2.85 1.87 0.92 3.02 1.86 0.93 3.19 1.99 0.94
AFR 16.0
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 4.58 3.13 1.09 5.10 3.15 1.10 5.27 3.42 1.11 5.62 3.43 1.12 5.79 3.71 1.13 6.14 3.69 1.14 6.49 3.93 1.15
25 4.37 2.99 1.24 4.86 3.00 1.26 5.03 3.27 1.26 5.36 3.28 1.27 5.53 3.54 1.28 5.86 3.52 1.29 6.19 3.75 1.31
30 4.14 2.83 1.38 4.61 2.85 1.40 4.77 3.10 1.41 5.08 3.11 1.43 5.24 3.35 1.43 5.56 3.34 1.45 5.87 3.56 1.46
35 3.95 2.70 1.51 4.40 2.72 1.53 4.55 2.95 1.54 4.85 2.96 1.55 5.00 3.20 1.53 5.30 3.19 1.58 5.60 3.40 1.59
40 3.52 2.40 1.51 3.92 2.42 1.53 4.05 2.63 1.54 4.32 2.64 1.56 4.45 2.85 1.57 4.72 2.84 1.58 4.99 3.02 1.60
43 3.27 2.24 1.50 3.64 2.25 1.53 3.77 2.44 1.54 4.01 2.45 1.55 4.14 2.65 1.56 4.39 2.64 1.58 4.64 2.81 1.59
AFR 16.0
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 5.79 4.38 1.35 6.45 4.41 1.37 6.67 4.79 1.38 7.11 4.81 1.39 7.33 5.19 1.40 7.77 5.17 1.40 8.21 5.51 1.40
25 5.53 4.18 1.53 6.16 4.21 1.55 6.37 4.57 1.56 6.79 4.59 1.57 7.00 4.95 1.58 7.42 4.93 1.58 7.84 5.26 1.58
30 5.26 3.98 1.70 5.86 4.00 1.73 6.06 4.35 1.74 6.46 4.37 1.76 6.66 4.72 1.76 7.06 4.70 1.76 7.46 5.00 1.76
35 4.98 3.76 1.88 5.54 3.79 1.91 5.73 4.12 1.92 6.11 4.13 1.94 6.30 4.46 1.95 6.68 4.44 1.95 7.06 4.73 1.95
40 4.67 3.53 2.07 5.20 3.55 2.10 5.38 3.86 2.11 5.74 3.88 2.13 5.91 4.19 2.14 6.27 4.17 2.14 6.62 4.44 2.14
43 4.48 3.39 2.18 4.99 3.41 2.21 5.16 3.71 2.22 5.50 3.72 2.25 5.67 4.01 2.26 6.01 4.00 2.26 6.35 4.26 2.26
