Fujitsu ASU18RLF Service Manual

43
41
42
42
45
44
48
46
50
51
47
INDOOR UNIT
COMPACT CASSETTE
AUU9RLF
AUU12RLF
AUU18RLF
532011.05.20
43 2 Stage Turbo Fan Assy 9375480011
41
41
Evaporator Total Assy (09, 12) 9377914033
Evaporator Total Assy (18) 9377914026
42 Evaporator Holder 9375508012
44 Fan Motor 9602870004
45 Fan Motor Holder 9375552015
48 Float Switch 9900361037
49 Drain Hose 9375519018
50 Drain Port 9375520014
51 Rubber (Pump) 9378426016
46 Pump Assy 9900472030
47 Drain Pump Holder B 9375518011
Ref. Description Part number
49
