5V
C201
0.1
<F>
R201
47
<1/4W>
C202
47/
10V
I C201
GP1UM261R
5V
5V
CN201
09 JB20/ZHR
1
1
1
1
2
2
2
2
2
1
3
VCC
OUT
GND
D206 SLR-325
D204 SLR-325
D203 SLR-325
D201 SLR-325
1
6
8
7
5
4
3
2
9
INDICATOR PCB ASSY
K03DV-0400WSE-D0
Models : ASU9RMLQ
ASU12RMLQ
ASU18RMLQ
112006.02.09
