Fujitsu ASU18RMLQ Service Manual

60
52
58
64
65
66
67
68
Connector : Black
Green
Blue
Red
Yellow
57
71
70
69
56
54
53
61
51
63
62
55
59
OUTDOOR UNIT
242007.10.18
51 Inverter Box A
52 Inverter Box B Assy
53 Inverter Box C
54 Inverter Box Duct
55 Inverter Box Cover
56 Heat Sink
57 Inverter Box D
58 Terminal (3P)
9374603015
9374625024
9374605026
9374609017
9374608010
9374607020
9374606023
9900203016
59 Terminal (6P)
60 Terminal
61 ACTPM
62 Power Supply PCB Assy
9900016036
9900433017
9703457012
9705647145
63 Controller PCB Assy
64 Heat Sink Thermistor
65 Compressor Thermistor
66 Thermistor (Outdoor Temp)
9705642256
9900311018
9900156022
9900378035
67 Heat Exchanger Thermistor
68 Discharge Thermistor
9900374020
9704219114
69 Fuse 0600384029
70 Fuse Holder
71 Fuse Holder Bracket
0500802111
9378287006
-- PTC Thermistor 9704265012
Ref. Description Part number
