OUTDOOR UNIT
33
33
38
32
42
35
34
46
45
41
31
40
39
34
232007.10.19
44
43
(Connector : red)
(Connector : white)
Ref. Description Part number
31 Compressor Assy
32 4-Way Valve
33 Inlet Pipe (Cond) A Assy
34 Outlet Pipe (Cond) A Assy
35 Pressure Switch
36 Pressure Switch
37 Accumulator Sub Assy
38 Receiver Tank Sub Assy
39 Expansion Valve Assy
40 Capillary Assy
41 Rubber Seat (For Comp)
9377946010
9900164010
9373461067
9374266067
9900186012
9900341015
9374426072
9373426028
9370947151
9372197370
9377951014
43
44 Pipe Thermistor (Red)
Pipe Thermistor (White) 9900373030
42 Solenoid 9900165055
9900373023
45 Oil Separater Assy 9367723027
46 Discharge Pipe A Assy 9372264225
-- Inlet Pipe (Cond) B Assy
-- Condensing Pipe A
-- Condensing C Assy
-- Strainer Assy
9373464082
9372232057
9375241032
9372524015
--
-- Compressor Cover A
Joint Pipe (Valve) Assy 9374840113
-- Suction Pipe C 9372177051
9374430055
-- Compressor Cover B 9374431052
-- Compressor Cover C 9372067048
To Next Page
