Fujitsu ASU18RMLQ User Manual

REPLACEMENT PARTS
03-25
PROCESS
MODEL : AOU24RML
USED
PARTS
Fig.1
EMI FILTER
BINDER C
EMI FILTER
BINDER C
70 10mm
Fig.2
Certainly fix EMI FILTER
to wires by BINDER.
W8 BLACK,W9 WHITE
(FILTER PCB)
EMI FILTER
BINDER C
Connect wires. (INVERTER BOX A)
REGULATIONS
As shown in Fig1-2, assemble EMI FILTER. Turn of the wire is according as Fig.1.
As shown in Fig.2, certainly fix EMI FILTER to wires by BINDER.
2 Turn the WIRE this way
Example of number of turns
of cores
1turn 2turns
Core
Core
1
2
1
2
1
2
+
-
