Fujitsu ASU24RLF Service Manual

2015.02.17 10
INDOOR UNIT SLIM DUCT ARU24RLF (Serial number : R)
43-5/16 inch 1100 mm
2-5/32 inch
55 mm
3-1/16 inch 78 mm
5-15/16 inch 151 mm
6-5/8 inch
168 mm
14-27/32 inch
377 mm
6-27/32 inch
174 mm
7-25/32 inch
198 mm
3-1/16 inch
78 mm
2-5/32 inch
55 mm
13/32 inch
10 mm
24-13/32 inch 620 mm
1-3/16 inch
30 mm
41-11/32 inch 1050 mm
44-21/32 inch 1134 mm
38-11/32 inch 974 mm
100 mm 1000 mm
3-15/16 x 10 = 39-3/8 inch
41-7/8 inch 1064 mm
