262015.02.18
OUTDOOR UNIT
AOU36RLXFZ1
PARTS
4 Top Panel Sub Assy
5 Front Panel Sub Assy
6 Rear Emblem
7
Service Panel Sub Assy
8 Right Panel Sub Assy
9 Valve Cover Sub Assy
1 Protective Net
2 Thermo Holder
9374417025
9374414079
9351355005
9374415038
9374416097
9374827015
10 Drain Assy
11 Drain Cap
9303029015
313166024302
9375381011
9375211011
Ref. Description Part number
5
7
10
1
6
11
4
9 8
2
3
Blue
3 Outdoor Thermistor 9900477035
