21 Propeller fan
22 Fan Motor
9366378020
9602843039
OUTDOOR UNIT
AOU36RLXFZ1
29 ACTPM
31 Power Supply PCB
9707592016
9709893098
27 Pipe Thermistor
30 Main PCB
23 Compressor Thermistor
28 Pipe Thermistor
9710113024
9900156084
9900543013
25
Heat Ex. Thermistor (Outlet)
26 Discharge Thermistor
9900492014
24
Heat Ex. Thermistor (Middle)
9900878009
9900621018
9900543020
Ref. Description Part number
25
24
23
30
27
26
29
21
31
22
28
Connector :
White
Green
White
Red
Red
Yellow
