8
4
3
9
5
10
7
1
2
INDOOR UNIT
COMPACT WALL MOUNTED
ASU7RLF1
ASU9RLF1
ASU12RLF1
2015.01.23
PARTS
30
5
8
9
7
Intake Grille printed (FUJITSU)
9333052052
6
Front Panel Sub Assy (FUJITSU)
9332994063
Bracket panel
3
Wire Cover 9332894011
Wire
shield
Electric Filter Holder 9332911008
4 Air Clean Filter Assy 9317250009
1 Remote Control 9320476007
2 Remote Control Holder 9318912005
Ref. Description Part number
Air Filter 9332875010
Louver 9333353005
10 Diffuser Assy 9332998009
6
