12
11
15
INDOOR UNIT
COMPACT WALL MOUNTED
ASU7RLF1
ASU9RLF1
ASU12RLF1
Control box
31
Terminal 9900720001
Main PCB (ASU9RLF1) 9709427330
13
Earth terminal
Control Box11
Cover shield
9332892024
Box shield assy
12
Main PCB (ASU7RLF1) 970942735412
Main PCB (ASU12RLF1)
970942734712
15
Room Thermistor Holder
9332868005
Ref. Description Part number
14
-- Thermistor Assy 9900714024
Display Assy 9709430019
2015.01.23
14
13
