Fujitsu ASU24RLF Service Manual

41
39
37
33
32 32
35
40
31
34
38
36
INDOOR UNIT COMPACT WALL MOUNTED ASU7RLF1 ASU9RLF1 ASU12RLF1 Casing assy
33
Fan Guard 9332905007
40 41
Step Motor 9900790004
36
Drain Hose Assy 9316904002
37
Step Motor 990079001138 Drain Cap 9316177017
31
Casing Cover B 9332908008
33
Casing Cover F 9332909005
32
R and L Louver A 9332891003 Casing
Conduit holder
9332890006
Cable Guide 9332903010 Motor Holder L/R 9332859003
39 34 35
Ref. Description Part number
2015.02.19
