INDOOR UNIT
COMPACT CASSETTE
AUU7RLF
AUU9RLF
AUU12RLF
AUU18RLF
2015.01.14 8
DECORATION PANEL
UTG-CCGF
20-7/8 inch 530 mm
5-5/16 inch
135 mm
9-27/32 inch
250 mm
27-9/16 inch 700 mm
27-9/16 inch 700 mm
2-15/16 inch
75 mm
21-1/4 inch 540 mm
22-7/16 inch 570 mm
Top view
Side view
5-3/4 inch
146 mm
9-21/32 inch
245 mm
Bottom view
1-3/16 inch
30 mm
1-15/16 inch
49 mm
Side view
