Fujitsu ASU9D Service Manual

– 1 –
SPECIFICATIONS
INDOOR UNIT ASU9RD ASU9RD x 2
OUTDOOR UNIT AOU18RD
COOLING CAPACITY
(BTU/hr)
9,300 - 9,600 18,600 - 18,800
HEATING CAPACITY 10,300 - 10,700 20,500 - 21,500
POWER SOURCE (V) 208 - 230
FREQUENCY (Hz) 60
RUNNING CURRENT (A)
COOLING 4.9 - 4.6 9.5 - 9.0
HEATING 4.6 - 4.4 8.5 - 8.1
INPUT WATTS (W)
COOLING 1,000 - 1,030 1,950 - 2,000
HEATING 940 - 980 1,650 - 1,750
SEER 10.5 11.0
MOISTURE REMOVAL Pts/hr (R/hr) 2.1 (1.0) 2.1 (1.0) + 2.1 (1.0)
AIR CIRCULATION-Hi (m
3
/hr) 510 510 + 510
ELECTRICAL DATA
COMPRESSOR
FAN MOTOR
DIMENSIONS
TYPE
Hermetic type, Permanent split condenser,
2 pole, Single phase, Induction motor
CODE
QK151KAA
208 - 230V 60Hz
REFRIGERANT R-22 lbs (g) 1.98 (900) x 2
POWER SOURCE (V) 208 - 230
HI COOL/HEAT (r.p.m.) 1,320 ± 20 / 1,300 ± 20
INDOOR UNIT
MED
COOL/HEAT (r.p.m.) 1,210 ± 20 / 1,200 ± 20
LO COOL/HEAT (r.p.m.) 1,100 ± 20 / 1,080 ± 20
QUIET COOL/HEAT (r.p.m.) 1,000 ± 20 / 960 ± 20
OUTDOOR UNIT (r.p.m.) 0,650 ±50 / 750 ± 50
INDOOR UNIT
H x W x D inch (mm)
11 (280) x 32-1/8 (815) x 7 (179)
OUTDOOR UNIT 25-6/16 (643) x 33-1/16 (840) x 13-3/16 (335)
WEIGHTS
INDOOR UNIT
GROSS / NET lbs (kg)
26 / 22 (12 / 10)
OUTDOOR UNIT 168 / 150 (76 / 68)

Fujitsu ASU9D Specifications

General

Brand	Fujitsu
Model	ASU9D
Category	Air Conditioner
Language	English
