Models : ASU9RD / AOU18RD
32-1/8” (815) 7 (179)
11 (280)
– 2 –
OUTLINE AND DIMENSIONS
INDOOR UNIT
Unit : inch (mm)
OUTDOOR UNIT
33-1/16”
(840)
13-3/16”
(336)
25-6/16”
(643)
13-3/16”
(333)
63/64” (25)
31-10/16” (804)
Mounting bolt pitch)
