WALL MOUNTED TYPE ASU9-15RL WALL MOUNTED TYPE ASU9-15RL
INSTALLATION PLACE

8QLWLQPP
59-1/16 (1500) or more
70-7/8 (1800) or more
2-15/32 (63) or more 1-25/32 (45) or more
1-7/8 (48) or more
2-1/16 (52) or more
Outline of unit
2-3/4 (70) or more
3-15/16 (100) or more
