Fujitsu ASU9RLF Design & Technical Manual

-
(
02 - 01
)
-
OUTDOOR UNIT AOU9-15RL OUTDOOR UNIT AOU9-15RL
SPECIFICATIONS1.
Type INVERTER HEAT PUMP
Model name AOU9RLFW AOU12RLFW AOU15RLS
Power sourse 208/230V~60HZ
Available voltage range 187-253V~60HZ
Starting current A 4.2 5.9 6.4
Fan
$LUÀRZUDWH
Cooling
CFM
(m
3
/h)
995(1690) 1036(1760) 1413(2400)
Heating 906(1540) 889(1510) 1177(2000)
Type×Q'ty Propeller fan×1
Motor output W 23 50 115
Sound pressure level
Cooling
dB(A)
48 49 51
Heating 48 49 51
Heat exchanger type
Dimensions
(H×W×D)
in. 19-27/32×25-9/32×1-7/16 19-27/32×35-9/32×1-7/16 23-5/32×34-11/16×1-7/16
mm 504×642×36.4 504×896×36.4 588×881×36.4
FPI (mm) 1.4
Rows×Stages 2×24 2×24 2×28
Pipe type Copper
Fin Type Aluminum
Compressor
Type×Q'ty Rotary×1
Motor output W 500 750 750
Refrigerant
Type R410A
Charge
lb.oz. 1lb.14oz. 2lb.5oz. 2lb.10.3oz.
kg 0.85 1.05 1.20
Refrigerant oil Type RB68 VG74 )5(2/Į6=
Enclosure
Material Steel
Colour
Beige
Approximate color of MUNSELL 10YR7.5/1.0
Dimensions
(H×W×D)
Net
mm 540×660×290 540×790×290 620×790×290
inch
21-11/32×22×
11-11/32
21-11/32×31-3/32×
11-11/32
24-1/2×31-3/32×
11-11/32
Gross
mm 611×797×401 625×919×385 712×935×400
inch
24-1/16×
31-3/8×15-25/32
24-19/32×
36-3/16×15-5/32
28-1/32×
36-13/16×15-3/4
Weight
Net
lb.(kg)
60(27) 80(36) 89(40)
Gross 67(30) 86(39) 97(44)
Connenction
pipe
Size
Liquid
in.
(mm)
Ø1/4(Ø6.35)
Gas Ø3/8(Ø9.52)
Method Flare
Max.length
ft.
(m)
66(20)[chargeless:49(15)]
Max.height difference 49(15)
Operation range
Cooling
°F
(°C)
14to115(-10 to 46)
Heating 5 to 75(-15to 24)
Note:
6SHFL¿FDWLRQVDUHEDVHGRQWKHIROORZLQJFRQGLWLRQV
Cooling:Indoor temperature of 80°F(26.67°C)DB/67°F(19.44°C)WB,and outdoor temperature of 95°F(35°C)DB/75°F(23.9°C)WB.
Heating:Indoor temperature of 70°F(21.11°C)DB/59°F(15°C)WB,and outdoor temperature of 47°F(8.33°C)DB/43°F(6.11°C)WB.
Pipe length:24ft.7in(7.5m),Height difference:0 m.(Outdoor unit-Indoor unit)
