Fujitsu ASU9RLS3Y User Manual

¢
Model: ASU15RLS3Y
AFR CFM 547
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW
15 12.72 9.80 0.36 14.18 10.92 0.36 15.63 12.04 0.38 16.10 12.40 0.37 17.04 13.13 0.37 18.02 13.88 0.38
23 12.53 9.62 0.39 13.95 10.72 0.39 15.38 11.82 0.41 15.85 12.18 0.40 16.78 12.90 0.40 17.75 13.63 0.42
32 12.33 9.49 0.40 13.73 10.57 0.41 15.14 11.65 0.43 15.60 12.01 0.42 16.52 12.72 0.42 17.47 13.45 0.43
41 12.13 9.34 0.41 13.51 10.41 0.41 14.89 11.47 0.43 15.35 11.82 0.42 16.26 12.52 0.42 17.19 13.24 0.44
50 11.93 9.18 0.42 13.29 10.23 0.42 14.65 11.27 0.45 15.10 11.62 0.43 16.00 12.31 0.44 16.91 13.01 0.45
59 11.73 9.01 0.45 13.07 10.04 0.45 14.41 11.07 0.48 14.85 11.41 0.46 15.74 12.10 0.46 16.64 12.78 0.48
67 13.48 11.10 0.72 15.01 11.17 0.74 16.55 12.15 0.75 17.06 13.14 0.75 18.08 13.07 0.76 19.11 13.95 0.76
77 12.86 10.57 0.82 14.33 10.64 0.83 15.80 11.59 0.84 16.27 12.50 0.84 17.23 12.47 0.85 18.22 13.28 0.86
87 12.18 10.00 0.91 13.58 10.07 0.92 14.98 10.99 0.94 15.42 11.87 0.95 16.34 11.84 0.95 17.30 12.61 0.96
95 11.46 9.40 1.01 12.76 9.48 1.02 14.06 10.32 1.03 14.50 11.17 1.04 15.35 11.10 1.05 16.24 11.84 1.06
104 10.06 8.28 0.99 11.22 8.31 1.01 12.35 9.09 1.02 12.73 9.79 1.02 13.51 9.76 1.03 14.26 10.39 1.05
115 9.18 7.54 0.97 10.20 7.57 0.99 11.26 8.28 1.01 11.60 8.91 1.01 12.32 8.88 1.02 13.00 9.48 1.03
AFR
m
3
/h
930
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 3.73 2.87 0.36 4.15 3.20 0.36 4.58 3.53 0.38 4.72 3.63 0.37 5.00 3.85 0.37 5.28 4.07 0.38
-5.0 3.67 2.82 0.39 4.09 3.14 0.39 4.51 3.46 0.41 4.65 3.57 0.40 4.92 3.78 0.40 5.20 4.00 0.42
0.0 3.61 2.78 0.40 4.02 3.10 0.41 4.44 3.42 0.43 4.57 3.52 0.42 4.84 3.73 0.42 5.12 3.94 0.43
5.0 3.56 2.74 0.41 3.96 3.05 0.41 4.37 3.36 0.43 4.50 3.46 0.42 4.77 3.67 0.42 5.04 3.88 0.44
10.0 3.50 2.69 0.42 3.90 3.00 0.42 4.29 3.30 0.45 4.43 3.41 0.43 4.69 3.61 0.44 4.96 3.81 0.45
15.0 3.44 2.64 0.45 3.83 2.94 0.45 4.22 3.24 0.48 4.35 3.34 0.46 4.61 3.54 0.46 4.88 3.75 0.48
19.4 3.95 3.25 0.72 4.40 3.27 0.74 4.85 3.56 0.75 5.00 3.85 0.75 5.30 3.83 0.76 5.60 4.09 0.76
25.0 3.77 3.10 0.82 4.20 3.12 0.83 4.63 3.40 0.84 4.77 3.66 0.84 5.05 3.65 0.85 5.34 3.89 0.86
30.6 3.57 2.93 0.91 3.98 2.95 0.92 4.39 3.22 0.94 4.52 3.48 0.95 4.79 3.47 0.95 5.07 3.70 0.96
35.0 3.36 2.76 1.01 3.74 2.78 1.02 4.12 3.02 1.03 4.25 3.27 1.04 4.50 3.25 1.05 4.76 3.47 1.06
40.0 2.95 2.43 0.99 3.29 2.44 1.01 3.62 2.66 1.02 3.73 2.87 1.02 3.96 2.86 1.03 4.18 3.05 1.05
46.0 2.69 2.21 0.97 2.99 2.22 0.99 3.30 2.43 1.01 3.40 2.61 1.01 3.61 2.60 1.02 3.81 2.78 1.03
- 10 -
5-1. Cooling capacity 5. Capacity table
WALL MOUNTED ASU9-15RLS3Y WALL MOUNTED ASU9-15RLS3Y

Fujitsu ASU9RLS3Y Specifications

General

Brand	Fujitsu
Model	ASU9RLS3Y
Category	Air Conditioner
Language	English
