Fujitsu ASU9RLS3Y User Manual

7. Additional charge calculation
7-1. Models: AOU9RLS3H and AOU12RLS3H
Refrigerant type R410A
Refrigerant amount
lb oz 2 lb 14 oz
g 1,300
¢ Refrigerant charge
Total pipe length
ft 49 or less 66 (Max.)
0.22 oz/ft
(20 g/m)
m 15 or less 20 (Max.)
Additional charge
oz 0 +3.5
g 0 +100
7-2. Model: AOU15RLS3H
Refrigerant type R410A
Refrigerant amount
lb oz 3 lb 1 oz
g 1,400
¢ Refrigerant charge
Total pipe length
ft 49 or less 66 (Max.)
0.22 oz/ft
(20 g/m)
m 15 or less 20 (Max.)
Additional charge
oz 0 +3.5
g 0 +100
- 51 -
7-1. Models: AOU9RLS3H and AOU12RLS3H 7. Additional charge calculation
OUTDOOR UNIT AOU9-15RLS3H OUTDOOR UNIT AOU9-15RLS3H

Fujitsu ASU9RLS3Y Specifications

General

Type	Wall Mounted
Cooling Capacity	2.5 kW
Heating Capacity	3.2 kW
Refrigerant	R32
Energy Efficiency Class Cooling	A+++
Energy Efficiency Class Heating	A++
Power Supply	230 V, 50 Hz
Weight (Outdoor Unit)	30 kg
Noise Level (Indoor)	19 dB
