1. Specifications
Type Inverter heat pump
Model name AOU9RLS3H AOU12RLS3H AOU15RLS3H
Power supply 208/230 V ~ 60 Hz
Available voltage range 188—253 V
Starting current A 3.3 4.7 5.2
Fan
Airflow rate
Cooling
CFM (m
3
/h)
989 (1,680) 1,206 (2,050)
Heating 1,082 (1,840)
Type × Q'ty Propeller fan × 1
Motor output W 49
Sound pressure level *1
Cooling
dB (A)
42 43 49
Heating 47 50
Heat exchanger type
Dimensions
(H × W × D)
in 23-1/8 × 34-11/16 × 1-7/16
mm 588 × 881 × 36.4
Fin pitch FPI 20
Rows × Stages 2 × 28
Pipe type Copper
Fin type
Type (Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance (Blue fin)
Compressor
Type × Q'ty Rotary × 1
Motor output W 850 1,000
Refrigerant
Type R410A
Charge
lb oz 2 lb 14 oz 3 lb 1 oz
g 1,300 1,400
Refrigerant oil
Type FREOL (ɑ68SZ)
Amount
in
3
(cm
3
)
12.5 (205)
Enclosure
Material Steel sheet
Color
Beige
Approximate color of Munsell 10YR 7.5/1.0
Dimensions
(H × W × D)
Net
in 24-1/2 × 31-1/8 × 11-7/16
mm 620 × 790 × 290
Gross
in 28-1/16 × 37-3/16 × 15-9/16
mm 713 × 945 × 395
Weight
Net
lb (kg)
86 (39) 88 (40)
Gross 95 (43)
Connection pipe
Size
Liquid
in (mm)
Ø 1/4 (Ø 6.35)
Gas Ø 3/8 (Ø 9.52) Ø 1/2 (Ø 12.7)
Method Flare
Pre-charge length
ft (m)
49 (15)
Max. length 66 (20)
Max. height difference 49 (15)
Operation range
Cooling
°F (°C)
14 to 115 (-10 to 46)
Heating -15 to 75 (-26 to 24)
Drain hose
Material LDPE
Size in (mm)
Ø 9/16 (Ø 13.8) [I. D.]
Ø5/8 to Ø11/16 (Ø 15.8 to Ø 16.7) [O. D.]
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 80 °FDB (26.67 °CDB) / 67 °FWB (19.44 °CWB), and outdoor temperature of 95 °FDB (35 °CDB) / 75 °FWB (23.9 °CWB).
– Heating: Indoor temperature of 70 °FDB (21.11 °CDB) / 59 °FWB (15 °CWB), and outdoor temperature of 47 °FDB (8.33 °CDB) / 43 °FWB (6.11 °CWB).
– Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m). (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
