Item no. Part no. Part name Service part
50 9387587128 Base assy ♦
51 9383765056 WLAN adapter holder assy ♦
52
9711732002 Main PCB (09 model) ♦
9711732019 Main PCB (12 model) ♦
53 9387488043 Cable guide ♦
54 9711146076 Display assy ♦
55 9711147011 Indicator PCB ♦
56 9901013010 Terminal ♦
57 9384500014 Motor case sub assy ♦
58 9379853026 DC fan motor ♦
59 9387713022 Motor cover assy ♦
60 9317250009 Air clean filter assy ♦
61 9332911008 Electric filter holder ♦
62 9387593396 Evaporator total assy ♦
63 9900627041 Thermistor assy ♦
64 9387467000 Room thermistor holder ♦
65 9333628004 Bearing D assy ♦
66 9387055047 Crossflow fan assy ♦
a — Box shield —
b — Control box —
c — PCB holder A —
d — Control cover —
e — Display case assy —
2-1. Models: ASUH09LMAS and ASUH12LMAS - (02-5) - 2. Indoor unit parts list
