4. Accessories
4-1. Indoor unit
¢
Models: ASUH09LMAS and ASUH12LMAS
Part name Exterior Q’ty Part name Exterior Q’ty
Operating manual 1 Tapping screw (large) 5
Installation manual 1 Tapping screw (small) 2
Wall hook bracket 1 Cloth tape 1
Remote controller 1 Filter holder 2
Remote controller
holder
1 Air cleaning filters 1
Battery 2
4-2. Outdoor unit
¢
Models: AOUH09LMAH1 and AOUH12LMBH1
Part name Exterior Qty Part name Exterior Qty
Installation manual 1 Cable tie 2
4-1. Indoor unit - (02-10) - 4. Accessories
