Page #23 background image
Item no. Part no. Part name Service part
50 9384354006 Compressor assy
51 9322444011 4-way valve assy
52 9970110160 Solenoid
53 9970222016 Expansion valve coil
54 9322463029 Pulse motor valve assy
55 9322474001 2-way valve assy
56 9322475008 3-way valve assy
57 9324024006 Sound insulator B
58 9322537003 Sound insulator H
59 9323045002 Sound insulator V
60 9322536020 Sound insulator F
61 9322386007 Rubber cushion
62 9313437008 Special nut
9900934040 Wire with connector (Fuse holder)
a Valve bracket
b Muffler
3-1. Models: AOUH09LMAH1 and AOUH12LMBH1 - (02-9) - 3. Outdoor unit parts list
