1. Specifications
1-1. Indoor unit
Type
Wall mounted
Inverter heat pump
Model name ASUH09LMAS ASUH12LMAS
Power supply 208/230 V~ 60 Hz
Power supply intake Outdoor unit
Available voltage range 187—253 V
Capacity
Cooling
Rated
kW 2.64 3.52
Btu/h 9,000 12,000
Min.—Max.
kW 1.00—3.37 1.00—3.90
Btu/h 3,400—11,500 3,400—13,300
Heating
Rated
kW 3.52 4.10
Btu/h 12,000 14,000
Min.—Max.
kW 0.82—4.69 0.82—5.60
Btu/h 2,800—16,000 2,800—19,100
Heating
(17°F) *
1
Rated
kW 2.17 2.49
Btu/h 7,400 8,500
Max.
kW 3.09 3.72
Btu/h 10,550 12,700
Heating
(5°F) *
2
Rated
kW 2.75 3.02
Btu/h 9,400 10,300
Max.
kW 2.78 3.14
Btu/h 9,480 10,700
Input power
Cooling
Rated
kW
0.585 0.96
Min.—Max. 0.14—1.27 0.14—1.27
Heating
Rated 0.79 0.99
Min.—Max. 0.14—1.67 0.14—1.67
Heating
(17°F) *
1
Rated 0.68 0.85
Max. 1.39 1.39
Heating
(5°F) *
2
Rated 1.37 1.38
Max. 1.38 1.38
Current
Cooling
Rated A
3.0 4.7
Heating 3.9 4.8
EER2 Cooling
kW/kW 4.51 3.66
Btu/hW 15.4 12.5
COP2 Heating
kW/kW 4.46 4.14
Btu/hW 15.2 14.1
SEER2 Cooling Btu/hW 26.5 23.0
HSPF2 Heating Btu/hW 12.3 11.0
Power factor
Cooling
%
84.8 88.8
Heating 88.1 89.7
Moisture removal pints/h (L/h) 2.7 (1.3) 3.8 (1.8)
Maximum operating current *
3
Cooling
A
6.9 6.9
Heating 9.4 9.4
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
453 (770)
MED 353 (600)
LOW 265 (450)
QUIET 147 (250)
Heating
HIGH 453 (770)
MED 377 (640)
LOW 306 (520)
QUIET 182 (310)
Type × Qty Crossflow fan × 1
Motor output W 49
Sound pressure level *
4
Cooling
HIGH
dB (A)
43
MED 36
LOW 30
QUIET 19
Heating
HIGH 43
MED 38
LOW 33
QUIET 21
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main1: 8-1/4 × 26-3/8 × 1-1/16 (210 × 670 × 26.6)
Main2: 4-7/16 × 26-3/8 × 13/16 (112 × 670 × 20)
Sub: 3-5/16 × 26-3/8 × 1/2 (84 × 670 × 13.3)
Fin pitch FPI
Man1: 21
Main2: 23
Sub: 18
Rows × Stages
Main1: 2 × 10
Main2: 2 × 7
Sub: 1 × 4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
in (mm)
10-5/8 × 32-13/16 × 8-3/4 (270 × 834 × 222)
Gross 10-7/8 × 36 × 13-1/16 (277 × 914 × 332)
Weight
Net
lb (kg)
22 (10)
Gross 29 (13)
Connection pipe
Size
Liquid
in (mm)
Ø1/4 (Ø6.35)
Gas Ø3/8 (Ø9.52)
Method Flare
Drain hose
Material PP+HDPE
Tip diameter in (mm) Ø17/32 (Ø13.8) (I.D.), Ø19/32 to 21/32 (Ø15.0 to 16.8) (O.D.)
1-1. Indoor unit - (01-1) - 1. Specifications
