Item no. Part no. Part name Service part
1 9322556028 Top panel assy
2 9377840004 Protective net
3 9322552259 Cabinet right assy
4 9384268006 Conduit cover
5 9322570055 Switch cover assy
6 9322138002 Thermistor holder
7
9709685792 Main PCB (Service) (09 model)
9709685808 Main PCB (Service) (12 model)
8 9900565060 Thermistor assy (Outdoor temp.)
9 9900935047 Thermistor assy
10 9900583019 Reactor assy
11 9384912008 Heat sink
12 9323550025 Base assy
13 9901060038 Base pan heater
14 9323540019 Heater holder A
15 9323541016 Heater holder B
16 9384265005 Fan guard
17 9322555335 Front panel assy
18 9322136008 Propeller fan
19 9603553005 DC fan motor
20 9322553010 Motor bracket assy
21 9323834019 Heat exchanger unit
a Hair pin cushion
3-1. Models: AOUH09LMAH1 and AOUH12LMBH1 - (02-7) - 3. Outdoor unit parts list
