Parts
Exterior Part name Model name Summary
Remote Sensor
Unit
UTY-XSZX
Thermo-sensor for sensing the
temperature of arbitrary place in the
room.
Auto Louver
Grille Kit
UTD-GXTA-W
Width: 26-7/8 in (683 mm)
For 07, 09, and 12 models
Auto Louver
Grille Kit
UTD-GXTB-W
Width: 34-3/4 in (883 mm)
For 18 model
Auto Louver
Grille Kit
UTD-GXTC-W
Width: 42-5/8 in (1,083 mm)
For 24 model
External
Connect Kit
UTY-XWZX
Use to connect with various peripheral
devices and air conditioner PCB.
External
Connect Kit
UTY-XWZXZ5
Required when external device is
connected.
External
Connect Kit
UTY-XWZXZG
Use to connect with various peripheral
devices and air conditioner PCB.
For control output port.
Air Outlet
Shutter Plate
UTR-YDZB
Installed at the air outlet when 3-
directions mode is performed.
Fresh Air Intake
Kit
UTZ-VXAA
By attaching Fresh Air Intake Kit to the
indoor unit, it can be taken in fresh air
of up to 10% of “high” air volume of
the indoor unit.
Do not branch the connecting duct into
multiple rooms.
Insulation Kit for
High Humidity
UTZ-KXGC
Install when the under-roof condition is
expected to be the humidity of over
80% and the temperature of over
86 °F(30 °C).
- 230 -
18-3. Others 18. Optional parts
MULTI-SPLIT TYPE
5-unit type
MULTI-SPLIT TYPE
5-unit type
