Fujitsu ASUH12LPAS User Manual

Combination of indoor unit
Type of in-
door unit
Rated capacity for each indoor
unit [kBtu/h]
Maximum capacity for each in-
door unit [kBtu/h]
Total capacity
[kBtu/h]
Input power [kW]
Unit
Total
Unit Unit
Min. Rated Max. Min. Rated Max.
1 2 3 4 5 1 2 3 4 5 1 2 3 4 5
9 9 9 15 — 42 Non-ducted 9.0 9.0 9.0 15.0 — 9.6 9.6 9.6 16.0 — 12.0 42.0 44.8 0.80 4.00 4.36
9 9 9 18 — 45 Non-ducted 9.0 9.0 9.0 18.0 — 9.6 9.6 9.6 19.2 — 12.0 45.0 48.0 0.80 4.37 4.77
9 9 9 24 — 51 Non-ducted 7.9 7.9 7.9 21.2 — 8.5 8.5 8.5 22.6 — 12.0 45.0 48.0 0.80 4.37 4.77
9 9 12 12 — 42 Non-ducted 9.0 9.0 12.0 12.0 — 9.6 9.6 12.8 12.8 — 12.0 42.0 44.8 0.80 4.00 4.36
9 9 12 15 — 45 Non-ducted 9.0 9.0 12.0 15.0 — 9.6 9.6 12.8 16.0 — 12.0 45.0 48.0 0.80 4.37 4.77
9 9 12 18 — 48 Non-ducted 8.4 8.4 11.3 16.9 — 9.0 9.0 12.0 18.0 — 12.0 45.0 48.0 0.80 4.37 4.77
9 9 12 24 — 54 Non-ducted 7.5 7.5 10.0 20.0 — 8.0 8.0 10.7 21.3 — 12.0 45.0 48.0 0.80 4.37 4.77
9 9 15 15 — 48 Non-ducted 8.4 8.4 14.1 14.1 — 9.0 9.0 15.0 15.0 — 12.0 45.0 48.0 0.80 4.28 4.77
9 9 15 18 — 51 Non-ducted 7.9 7.9 13.2 15.9 — 8.5 8.5 14.1 16.9 — 12.0 45.0 48.0 0.80 4.28 4.77
9 9 18 18 — 54 Non-ducted 7.5 7.5 15.0 15.0 — 8.0 8.0 16.0 16.0 — 12.0 45.0 48.0 0.80 4.28 4.77
9 12 12 12 — 45 Non-ducted 9.0 12.0 12.0 12.0 — 9.6 12.8 12.8 12.8 — 12.0 45.0 48.0 0.80 4.28 4.77
9 12 12 15 — 48 Non-ducted 8.4 11.3 11.3 14.1 — 9.0 12.0 12.0 15.0 — 12.0 45.0 48.0 0.80 4.28 4.77
9 12 12 18 — 51 Non-ducted 7.9 10.6 10.6 15.9 — 8.5 11.3 11.3 16.9 — 12.0 45.0 48.0 0.80 4.28 4.77
9 12 15 15 — 51 Non-ducted 7.9 10.6 13.2 13.2 — 8.5 11.3 14.1 14.1 — 12.0 45.0 48.0 0.80 3.45 4.77
9 12 15 18 — 54 Non-ducted 7.5 10.0 12.5 15.0 — 8.0 10.7 13.3 16.0 — 12.0 45.0 48.0 0.80 4.28 4.77
12 12 12 12 — 48 Non-ducted 11.3 11.3 11.3 11.3 — 12.0 12.0 12.0 12.0 — 12.0 45.0 48.0 0.80 4.28 4.77
12 12 12 15 — 51 Non-ducted 10.6 10.6 10.6 13.2 — 11.3 11.3 11.3 14.1 — 12.0 45.0 48.0 0.80 4.28 4.77
12 12 12 18 — 54 Non-ducted 10.0 10.0 10.0 15.0 — 10.7 10.7 10.7 16.0 — 12.0 45.0 48.0 0.80 4.28 4.77
12 12 12 18 — 54 Non-ducted 10.0 10.0 10.0 15.0 — 10.7 10.7 10.7 16.0 — 12.0 45.0 48.0 0.80 4.37 4.77
12 12 15 15 — 54 Non-ducted 10.0 10.0 12.5 12.5 — 10.7 10.7 13.3 13.3 — 12.0 45.0 48.0 0.80 4.37 4.77
7 7 7 7 7 35 Non-ducted 7.0 7.0 7.0 7.0 7.0 7.5 7.5 7.5 7.5 7.5 12.0 35.0 37.3 0.80 2.94 3.26
7 7 7 7 9 37 Non-ducted 7.0 7.0 7.0 7.0 9.0 7.5 7.5 7.5 7.5 9.6 12.0 37.0 39.5 0.80 3.22 3.58
7 7 7 7 12 40 Non-ducted 7.0 7.0 7.0 7.0 12.0 7.5 7.5 7.5 7.5 12.8 12.0 40.0 42.7 0.80 3.64 4.05
7 7 7 7 15 43 Non-ducted 7.0 7.0 7.0 7.0 15.0 7.5 7.5 7.5 7.5 16.0 12.0 43.0 45.9 0.80 4.05 4.52
7 7 7 7 18 46 Non-ducted 6.8 6.8 6.8 6.8 17.6 7.3 7.3 7.3 7.3 18.8 12.0 45.0 48.0 0.80 4.28 4.77
7 7 7 7 24 52 Non-ducted 6.1 6.1 6.1 6.1 20.8 6.5 6.5 6.5 6.5 22.2 12.0 45.0 48.0 0.80 4.28 4.77
7 7 7 9 9 39 Non-ducted 7.0 7.0 7.0 9.0 9.0 7.5 7.5 7.5 9.6 9.6 12.0 39.0 41.6 0.80 3.50 3.89
7 7 7 9 12 42 Non-ducted 7.0 7.0 7.0 9.0 12.0 7.5 7.5 7.5 9.6 12.8 12.0 42.0 44.8 0.80 3.92 4.36
7 7 7 9 15 45 Non-ducted 7.0 7.0 7.0 9.0 15.0 7.5 7.5 7.5 9.6 16.0 12.0 45.0 48.0 0.80 4.28 4.77
7 7 7 9 18 48 Non-ducted 6.6 6.6 6.6 8.4 16.9 7.0 7.0 7.0 9.0 18.0 12.0 45.0 48.0 0.80 4.28 4.77
7 7 7 9 24 54 Non-ducted 5.8 5.8 5.8 7.5 20.0 6.2 6.2 6.2 8.0 21.3 12.0 45.0 48.0 0.80 4.28 4.77
7 7 7 12 12 45 Non-ducted 7.0 7.0 7.0 12.0 12.0 7.5 7.5 7.5 12.8 12.8 12.0 45.0 48.0 0.80 4.28 4.77
7 7 7 12 15 48 Non-ducted 6.6 6.6 6.6 11.3 14.1 7.0 7.0 7.0 12.0 15.0 12.0 45.0 48.0 0.80 4.28 4.77
7 7 7 12 18 51 Non-ducted 6.2 6.2 6.2 10.6 15.9 6.6 6.6 6.6 11.3 16.9 12.0 45.0 48.0 0.80 4.28 4.77
7 7 7 15 15 51 Non-ducted 6.2 6.2 6.2 13.2 13.2 6.6 6.6 6.6 14.1 14.1 12.0 45.0 48.0 0.80 4.28 4.77
7 7 7 15 18 54 Non-ducted 5.8 5.8 5.8 12.5 15.0 6.2 6.2 6.2 13.3 16.0 12.0 45.0 48.0 0.80 4.28 4.77
7 7 9 9 9 41 Non-ducted 7.0 7.0 9.0 9.0 9.0 7.5 7.5 9.6 9.6 9.6 12.0 41.0 43.7 0.80 3.78 4.20
7 7 9 9 12 44 Non-ducted 7.0 7.0 9.0 9.0 12.0 7.5 7.5 9.6 9.6 12.8 12.0 44.0 46.9 0.80 4.20 4.67
7 7 9 9 15 47 Non-ducted 6.7 6.7 8.6 8.6 14.4 7.1 7.1 9.2 9.2 15.3 12.0 45.0 48.0 0.80 4.28 4.77
7 7 9 9 18 50 Non-ducted 6.3 6.3 8.1 8.1 16.2 6.7 6.7 8.6 8.6 17.3 12.0 45.0 48.0 0.80 4.28 4.77
7 7 9 12 12 47 Non-ducted 6.7 6.7 8.6 11.5 11.5 7.1 7.1 9.2 12.3 12.3 12.0 45.0 48.0 0.80 4.28 4.77
7 7 9 12 15 50 Non-ducted 6.3 6.3 8.1 10.8 13.5 6.7 6.7 8.6 11.5 14.4 12.0 45.0 48.0 0.80 4.28 4.77
7 7 9 12 18 53 Non-ducted 5.9 5.9 7.6 10.2 15.3 6.3 6.3 8.2 10.9 16.3 12.0 45.0 48.0 0.80 4.28 4.77
7 7 9 15 15 53 Non-ducted 5.9 5.9 7.6 12.7 12.7 6.3 6.3 8.2 13.6 13.6 12.0 45.0 48.0 0.80 3.45 4.77
7 7 12 12 12 50 Non-ducted 6.3 6.3 10.8 10.8 10.8 6.7 6.7 11.5 11.5 11.5 12.0 45.0 48.0 0.80 4.28 4.77
7 7 12 12 15 53 Non-ducted 5.9 5.9 10.2 10.2 12.7 6.3 6.3 10.9 10.9 13.6 12.0 45.0 48.0 0.80 4.28 4.77
7 9 9 9 9 43 Non-ducted 7.0 9.0 9.0 9.0 9.0 7.5 9.6 9.6 9.6 9.6 12.0 43.0 45.9 0.80 4.05 4.52
7 9 9 9 12 46 Non-ducted 6.8 8.8 8.8 8.8 11.7 7.3 9.4 9.4 9.4 12.5 12.0 45.0 48.0 0.80 4.28 4.77
7 9 9 9 15 49 Non-ducted 6.4 8.3 8.3 8.3 13.8 6.9 8.8 8.8 8.8 14.7 12.0 45.0 48.0 0.80 4.28 4.77
7 9 9 9 18 52 Non-ducted 6.1 7.8 7.8 7.8 15.6 6.5 8.3 8.3 8.3 16.6 12.0 45.0 48.0 0.80 4.28 4.77
7 9 9 12 12 49 Non-ducted 6.4 8.3 8.3 11.0 11.0 6.9 8.8 8.8 11.8 11.8 12.0 45.0 48.0 0.80 4.28 4.77
7 9 9 12 15 52 Non-ducted 6.1 7.8 7.8 10.4 13.0 6.5 8.3 8.3 11.1 13.8 12.0 45.0 48.0 0.80 4.28 4.77
7 9 12 12 12 52 Non-ducted 6.1 7.8 10.4 10.4 10.4 6.5 8.3 11.1 11.1 11.1 12.0 45.0 48.0 0.80 4.28 4.77
9 9 9 9 9 45 Non-ducted 9.0 9.0 9.0 9.0 9.0 9.6 9.6 9.6 9.6 9.6 12.0 45.0 48.0 0.80 4.28 4.77
9 9 9 9 12 48 Non-ducted 8.4 8.4 8.4 8.4 11.3 9.0 9.0 9.0 9.0 12.0 12.0 45.0 48.0 0.80 4.36 4.86
9 9 9 9 15 51 Non-ducted 7.9 7.9 7.9 7.9 13.2 8.5 8.5 8.5 8.5 14.1 12.0 45.0 48.0 0.80 4.36 4.86
9 9 9 9 18 54 Non-ducted 7.5 7.5 7.5 7.5 15.0 8.0 8.0 8.0 8.0 16.0 12.0 45.0 48.0 0.80 4.36 4.86
9 9 9 12 12 51 Non-ducted 7.9 7.9 7.9 10.6 10.6 8.5 8.5 8.5 11.3 11.3 12.0 45.0 48.0 0.80 4.36 4.86
9 9 9 12 15 54 Non-ducted 7.5 7.5 7.5 10.0 12.5 8.0 8.0 8.0 10.7 13.3 12.0 45.0 48.0 0.80 4.36 4.86
9 9 12 12 12 54 Non-ducted 7.5 7.5 10.0 10.0 10.0 8.0 8.0 10.7 10.7 10.7 12.0 45.0 48.0 0.80 4.36 4.86
12 24 — — — 36 Ducted 12.0 24.0 — — — 12.8 25.6 — — — 12.0 36.0 38.4 0.80 3.49 3.48
18 18 — — — 36 Ducted 18.0 18.0 — — — 19.2 19.2 — — — 12.0 36.0 38.4 0.80 3.49 3.48
18 24 — — — 42 Ducted 18.0 24.0 — — — 19.2 25.6 — — — 12.0 42.0 44.8 0.80 4.46 4.44
24 24 — — — 48 Ducted 22.5 22.5 — — — 24.0 24.0 — — — 12.0 45.0 48.0 0.80 4.88 4.86
7 7 24 — — 38 Ducted 7.0 7.0 24.0 — — 7.5 7.5 25.6 — — 12.0 38.0 40.5 0.80 3.74 3.80
7 9 18 — — 34 Ducted 7.0 9.0 18.0 — — 7.5 9.6 19.2 — — 12.0 34.0 36.3 0.80 3.10 3.15
7 9 24 — — 40 Ducted 7.0 9.0 24.0 — — 7.5 9.6 25.6 — — 12.0 40.0 42.7 0.80 4.05 4.12
7 12 18 — — 37 Ducted 7.0 12.0 18.0 — — 7.5 12.8 19.2 — — 12.0 37.0 39.5 0.80 3.57 3.64
7 12 24 — — 43 Ducted 7.0 12.0 24.0 — — 7.5 12.8 25.6 — — 12.0 43.0 45.9 0.80 4.34 4.60
7 18 18 — — 43 Ducted 7.0 18.0 18.0 — — 7.5 19.2 19.2 — — 12.0 43.0 45.9 0.80 4.34 4.60
7 18 24 — — 49 Ducted 6.4 16.5 22.0 — — 6.9 17.6 23.5 — — 12.0 45.0 48.0 0.80 3.75 4.86
9 9 18 — — 36 Ducted 9.0 9.0 18.0 — — 9.6 9.6 19.2 — — 12.0 36.0 38.4 0.80 3.28 3.48
9 9 24 — — 42 Ducted 9.0 9.0 24.0 — — 9.6 9.6 25.6 — — 12.0 42.0 44.8 0.80 4.19 4.44
9 12 18 — — 39 Ducted 9.0 12.0 18.0 — — 9.6 12.8 19.2 — — 12.0 39.0 41.6 0.80 3.89 3.96
9 12 24 — — 45 Ducted 9.0 12.0 24.0 — — 9.6 12.8 25.6 — — 12.0 45.0 48.0 0.80 4.78 4.86
9 18 18 — — 45 Ducted 9.0 18.0 18.0 — — 9.6 19.2 19.2 — — 12.0 45.0 48.0 0.80 4.78 4.86
9 18 24 — — 51 Ducted 7.9 15.9 21.2 — — 8.5 16.9 22.6 — — 12.0 45.0 48.0 0.80 4.78 4.86
12 12 12 — — 36 Ducted 12.0 12.0 12.0 — — 12.8 12.8 12.8 — — 12.0 36.0 38.4 0.80 3.28 3.48
12 12 18 — — 42 Ducted 12.0 12.0 18.0 — — 12.8 12.8 19.2 — — 12.0 42.0 44.8 0.80 4.19 4.44
12 12 24 — — 48 Ducted 11.3 11.3 22.5 — — 12.0 12.0 24.0 — — 12.0 45.0 48.0 0.80 4.59 4.86
12 18 18 — — 48 Ducted 11.3 16.9 16.9 — — 12.0 18.0 18.0 — — 12.0 45.0 48.0 0.80 4.59 4.86
12 18 24 — — 54 Ducted 10.0 15.0 20.0 — — 10.7 16.0 21.3 — — 12.0 45.0 48.0 0.80 4.59 4.86
18 18 18 — — 54 Ducted 15.0 15.0 15.0 — — 16.0 16.0 16.0 — — 12.0 45.0 48.0 0.80 4.78 4.86
7 7 7 18 — 39 Ducted 7.0 7.0 7.0 18.0 — 7.5 7.5 7.5 19.2 — 12.0 39.0 41.6 0.80 3.81 3.96
7 7 7 24 — 45 Ducted 7.0 7.0 7.0 24.0 — 7.5 7.5 7.5 25.6 — 12.0 45.0 48.0 0.80 4.59 4.86
7 7 9 12 — 35 Ducted 7.0 7.0 9.0 12.0 — 7.5 7.5 9.6 12.8 — 12.0 35.0 37.3 0.80 3.13 3.32
7 7 9 18 — 41 Ducted 7.0 7.0 9.0 18.0 — 7.5 7.5 9.6 19.2 — 12.0 41.0 43.7 0.80 4.04 4.28
7 7 9 24 — 47 Ducted 6.7 6.7 8.6 23.0 — 7.1 7.1 9.2 24.5 — 12.0 45.0 48.0 0.80 4.59 4.86
7 7 12 12 — 38 Ducted 7.0 7.0 12.0 12.0 — 7.5 7.5 12.8 12.8 — 12.0 38.0 40.5 0.80 3.16 3.80
- 247 -
6-1. Combinations 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ

Fujitsu ASUH12LPAS Specifications
