Fujitsu ASUH12LPAS User Manual

Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
15.6 °CDB 18.3 °CDB 21.1 °CDB 23.9 °CDB 25.6 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
37
-15.0
-16.1 7.98 3.83 7.79 3.91 7.60 3.99 7.41 4.07 7.22 4.15
-10.0 -11.1 8.99 3.83 8.78 3.91 8.50 3.99 8.35 4.07 8.14 4.15
-5.0 -7.2 10.01 3.83 9.77 3.91 9.50 3.99 9.30 4.07 9.06 4.15
0.0 -2.2 11.67 3.83 11.39 3.91 11.10 3.99 10.83 4.07 10.55 4.15
5.0 2.8 13.32 3.83 13.00 3.91 12.60 3.99 12.37 4.07 12.05 4.15
8.3 6.1 13.66 3.44 13.33 3.51 13.00 3.58 12.68 3.66 12.36 3.73
10.0 8.3 13.66 3.44 13.33 3.51 13.00 3.58 12.68 3.66 12.36 3.73
15.0 10.0 13.66 3.21 13.33 3.27 13.00 3.34 12.68 3.41 12.36 3.47
20.0 15.0 13.03 2.78 12.72 2.83 12.40 2.89 12.10 2.95 11.79 3.01
23.9 18.3 12.42 2.54 12.13 2.59 11.80 2.64 11.54 2.70 11.24 2.75
36
-15.0
-16.1 7.76 3.72 7.58 3.79 7.30 3.87 7.21 3.95 7.02 4.02
-10.0 -11.1 8.75 3.72 8.54 3.79 8.30 3.87 8.13 3.95 7.92 4.02
-5.0 -7.2 9.74 3.72 9.51 3.79 9.20 3.87 9.05 3.95 8.81 4.02
0.0 -2.2 11.35 3.72 11.08 3.79 10.80 3.87 10.54 3.95 10.27 4.02
5.0 2.8 12.96 3.72 12.65 3.79 12.30 3.87 12.03 3.95 11.72 4.02
8.3 6.1 13.29 3.34 12.97 3.41 12.60 3.48 12.34 3.55 12.02 3.62
10.0 8.3 13.29 3.34 12.97 3.41 12.60 3.48 12.34 3.55 12.02 3.62
15.0 10.0 13.29 3.11 12.97 3.18 12.60 3.24 12.34 3.31 12.02 3.37
20.0 15.0 12.68 2.70 12.38 2.75 12.00 2.81 11.78 2.86 11.47 2.92
23.9 18.3 12.09 2.46 11.80 2.52 11.50 2.57 11.22 2.62 10.94 2.67
35
-15.0
-16.1 7.54 3.60 7.36 3.68 7.10 3.75 7.01 3.83 6.83 3.90
-10.0 -11.1 8.51 3.60 8.30 3.68 8.10 3.75 7.90 3.83 7.70 3.90
-5.0 -7.2 9.47 3.60 9.25 3.68 9.00 3.75 8.79 3.83 8.57 3.90
0.0 -2.2 11.03 3.60 10.77 3.68 10.50 3.75 10.25 3.83 9.98 3.90
5.0 2.8 12.60 3.60 12.30 3.68 12.00 3.75 11.70 3.83 11.40 3.90
8.3 6.1 12.92 3.24 12.61 3.31 12.30 3.38 12.00 3.44 11.69 3.51
10.0 8.3 12.92 3.24 12.61 3.31 12.30 3.38 12.00 3.44 11.69 3.51
15.0 10.0 12.92 3.02 12.61 3.08 12.30 3.15 12.00 3.21 11.69 3.27
20.0 15.0 12.33 2.62 12.04 2.67 11.70 2.72 11.45 2.78 11.16 2.83
23.9 18.3 11.75 2.39 11.47 2.44 11.10 2.49 10.91 2.54 10.63 2.59
34
-15.0
-16.1 7.33 3.49 7.15 3.57 6.90 3.64 6.80 3.71 6.63 3.79
-10.0 -11.1 8.26 3.49 8.07 3.57 7.80 3.64 7.67 3.71 7.48 3.79
-5.0 -7.2 9.20 3.49 8.98 3.57 8.70 3.64 8.54 3.71 8.32 3.79
0.0 -2.2 10.72 3.49 10.46 3.57 10.20 3.64 9.95 3.71 9.70 3.79
5.0 2.8 12.24 3.49 11.95 3.57 11.60 3.64 11.36 3.71 11.07 3.79
8.3 6.1 12.55 3.15 12.25 3.21 11.90 3.28 11.65 3.34 11.35 3.41
10.0 8.3 12.55 3.15 12.25 3.21 11.90 3.28 11.65 3.34 11.35 3.41
15.0 10.0 12.55 2.93 12.25 2.99 11.90 3.05 11.65 3.11 11.35 3.17
20.0 15.0 11.98 2.54 11.69 2.59 11.40 2.64 11.12 2.70 10.84 2.75
23.9 18.3 11.42 2.32 11.14 2.37 10.80 2.42 10.60 2.46 10.33 2.51
NOTE:
Specifications are based on the following conditions.
• Power source of specifications: 230 V
• 2 or more indoor units should be connected.
• Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
• The total ability of connected a indoor unit is from 34,000 Btu up to 54,000 Btu.
• Input in the table are calculated based on the maximum indoor unit input combina-
tions.
- 279 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ

Fujitsu ASUH12LPAS Specifications

General

Brand	Fujitsu
Model	ASUH12LPAS
Category	Air Conditioner
Language	English
