Fujitsu ASUH24LPAS Service Manual

1. Specifications
1-1. Indoor unit
Type
Wall mounted
Inverter heat pump
Model name ASUH18LPAS ASUH24LPAS
Power supply 208/230 V ~60 Hz
Power supply intake Outdoor unit
Available voltage range 187—253 V
Capacity
Cooling
Rated
kW 5.28 7.03
Btu/h 18,000 24,000
Min.—Max.
kW 1.17—5.57 1.17—7.15
Btu/h 4,000—19,000 4,000—24,400
Heating
Rated
kW 5.28 7.03
Btu/h 18,000 24,000
Min.—Max.
kW 0.82—7.03 0.85—8.50
Btu/h 2,800—24,000 2,900—29,000
Heating (17°F)*
1
Rated
kW 3.28 4.51
Btu/h 11,200 15,400
Max.
kW 4.40 5.57
Btu/h 15,000 19,000
Heating (5°F)*
2
Rated
kW 5.3 5.71
Btu/h 18,100 19,500
Max.
kW 5.55 5.71
Btu/h 18,600 19,500
Input power
Cooling
Rated
kW
1.50 2.60
Min.—Max. 0.15—1.90 0.15—3.20
Heating
Rated 1.33 2.07
Min.—Max. 0.15—2.10 0.15—3.10
Heating (17°F)*
1
Rated 1.12 1.58
Max. 1.70 2.20
Heating (5°F)*
2
Rated 2.47 2.85
Max. 2.50 2.85
Current
Cooling
Rated A
6.7 11.4
Heating 5.9 9.1
EER2 Cooling
kW/kW 3.52 2.7
Btu/hW 12.0 9.2
COP2 Heating
kW/kW 3.96 3.4
Btu/hW 13.5 11.6
SEER2 Cooling Btu/hW 20.0 19.0
HSPF2 Heating Btu/hW 10.5 9.8
Power factor
Cooling
%
97.3 99.2
Heating 98.0 98.9
Moisture removal pints/h (L/h) 4.0 (1.9) 6.3 (3.0)
Maximum operating current*
3
Cooling
A
9.9 14.4
Heating 11.9 13.9
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
530 (900) 642 (1,090)
MED 471 (800) 471 (800)
LOW 377 (640) 377 (640)
QUIET 241 (410) 306 (520)
Heating
HIGH 506 (860) 594 (1,010)
MED 406 (690) 506 (860)
LOW 330 (560) 377 (640)
QUIET 247 (420) 306 (520)
Type × Qty Crossflow fan × 1
Motor output W 59
Sound pressure level*
4
Cooling
HIGH
dB (A)
44 49
MED 42
LOW 37
QUIET 26 31
Heating
HIGH 43 47
MED 39 43
LOW 34 37
QUIET 28 32
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main1: 8-1/4 × 31-5/16 × 1-1/16 (210 × 796 × 26.6)
Main2: 4-15/16 × 31-5/16 × 1-1/16 (126 × 796 × 26.6)
Sub1: 3-5/16 × 31-5/16 × 1/2 (84 × 796 × 13.3)
Fin pitch FPI
Man1: 21
Main2: 21
Sub1: 18
Rows × Stages
Main1: 2 × 10
Main2: 2 × 6
Sub1: 1 × 4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
in (mm)
11 × 38-9/16 × 9-7/16 (280 × 980 × 240)
Gross 12-11/16 × 42-7/16 × 13-5/8 (322 × 1,078 × 346)
Weight
Net
lb (kg)
29 (13)
Gross 37 (17)
Connection pipe
Size
Liquid
in (mm)
Ø1/4 (Ø6.35)
Gas Ø1/2 (Ø12.7)
Method Flare
Drain hose
Material PP+HDPE
Tip diameter in (mm) Ø17/32 (Ø13.8) (I.D.), Ø5/8 to 21/32 (Ø15.8 to 16.7) (O.D.)
1-1. Indoor unit - (01-1) - 1. Specifications
