Fujitsu ASUH24LPAS Service Manual

Type
Wall mounted
Inverter heat pump
Model name ASUH18LPAS ASUH24LPAS
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 86 or less (30 or less)
Remote controller type
Wireless (Wired, Mobile app*
5
[FGLair
™
] [option])
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 80°FDB (26.67°CDB)/67°FWB (19.44°CWB), and outdoor temperature of 95°FDB (35°CDB)/75°FWB (23.9°CWB).
– Heating: Indoor temperature of 70°FDB (21.11°CDB)/59°FWB (15.56°CWB), and outdoor temperature of 47°FDB (8.33°CDB)/43°FWB (6.11°CWB).
– *1: Heating (17°F): Indoor temperature of 70°FDB (21.11°CDB) /60°FWB (15.56°CWB), and outdoor temperature of 17°FDB (-8.33°CDB)/15°FWB (-9.44°CWB).
– *2: Heating (5°F): Indoor temperature of 70°FDB (21.11°CDB)/60°FWB (15.56°CWB), and outdoor temperature of 5°FDB (-15.0°CDB)/4°FWB (-15.56°CWB).
– Test conditions are based on AHRI 210/240 2023.
– Pipe length: 25 ft (7.5 m), Height difference: 0 ft (0 m). (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *3: Maximum current is maximum value when operated within the operation range.
• *4: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *5: Available on Google Play
™
store or on App Store
®
. Optional WLAN Adapter is also required. For details, refer to the setting manual.
M condition
Model name ASUH18LPAS ASUH24LPAS
Capacity
Cooling
Rated
kW 5.28 7.03
Btu/h 18,000 24,000
Min.—Max.
kW 1.17—5.57 1.17—7.15
Btu/h 4,000—19,000 4,000—24,400
Heating
Rated
kW 5.28 7.03
Btu/h 18,000 24,000
Min.—Max.
kW 0.82—7.03 0.85—8.50
Btu/h 2,800—24,000 2,900—29,000
Heating (17°F)*
Rated
kW 3.28 4.51
Btu/h 11,200 15,400
Max.
kW 4.40 5.57
Btu/h 15,000 19,000
Input power
Cooling
Rated
kW
1.50 2.60
Min.—Max. 0.15—1.90 0.15—3.20
Heating
Rated 1.33 2.07
Min.—Max. 0.15—2.10 0.15—3.10
Heating (17°F)*
Rated 1.12 1.58
Max. 1.70 2.20
Current
Cooling
Rated A
6.7 11.4
Heating 5.9 9.1
EER Cooling
kW/kW 3.52 2.70
Btu/hW 12.0 9.2
COP Heating
kW/kW 3.96 3.40
Btu/hW 13.5 11.6
SEER Cooling Btu/hW 20.0 19.0
HSPF Heating Btu/hW 11.0
Power factor
Cooling
%
97.3 99.2
Heating 98.0 98.9
NOTES:
Specifications are based on the following conditions:
• Cooling: Indoor temperature of 80°FDB (26.67°CDB)/67°FWB (19.44°CWB), and outdoor temperature of 95°FDB (35°CDB)/75°FWB (23.9°CWB).
• Heating: Indoor temperature of 70°FDB (21.11°CDB)/59°FWB (15.56°CWB), and outdoor temperature of 47°FDB (8.33°CDB)/43°FWB (6.11°CWB).
• *: Heating (17°F): Indoor temperature of 70°FDB (21.11°CDB)/60°FWB (15.56°CWB), and outdoor temperature of 17°FDB (-8.33°CDB)/15°FWB (-9.44°CWB).
• Test conditions are based on AHRI 210/240 2017.
• Pipe length: 25 ft (7.5 m), Height difference: 0 ft (0 m). (Between outdoor unit and indoor unit.)
1-1. Indoor unit
- (01-2) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

Fujitsu ASUH24LPAS Specifications
