8-3. Combination of external input and output
By combining the function setting of the indoor unit and rotary switch setting of the External input
and output PCB, you can select various combinations of functions.
Combination examples of external input and output are as follows:
Mode
Function
setting
Rotary
SW
External input
Indoor unit External input and output PCB
CN46
1
CN313
2
CN314
0-1 60—00 1
Operation/Stop
(Function setting 46-00)
or
Forced stop
(Function setting 46-02)
Operation/Stop Not available
Operation Stop
0-2 60-00 2 Forced thermostat Off
Not available
1 60-01 3
Mechanical cooling
Off
2 60-02 4 Forced thermostat Off
3 60-03 5
Mechanical cooling
On
4 60-04 6
Mechanical cooling
On
5 60-05 7 Forced thermostat Off
6 60-06 8 Forced thermostat Off
7 60-07 9
Mechanical cooling
Off
8 60-08 A Forced thermostat Off
9 60-09 B Forced thermostat Off
10 60-10 C Forced thermostat Off
11 60-11 D Forced thermostat Off
NOTE: Input of Operation/Stop depends on the setting of function setting 46.
00: Operation/Stop mode 1 (R.C. enabled)
01: (Setting prohibited)
02: Forced stop
03: Operation/Stop mode 2 (R.C. disabled)
- 19 -
8-3. Combination of external input and output
8. External input and output
WALL MOUNTED ASUH30-36LPAS WALL MOUNTED ASUH30-36LPAS
