Fujitsu ASY14FSACW User Manual

1 2003.11.26
S PE CIFICATION S
TY PE COOL COOL & HEAT
INDOO R U NIT AS Y 14FS AC W AS Y 14US A CW
OU TDOOR UN IT AOY 14FS A C AOY 14U S AC
COOLIN G CAPACITY (kW ) 4.10 - 4.15 3.95 - 4.00
HE A T IN G C A PA C IT Y (kW ) ----- 4.85 - 4.95
POW ER S OU R CE (V ) 220 - 240
FR E Q U E NCY (Hz) 50
R U NN IN G CU R R E N T (A )
COOLIN G 7.2 - 7.3 7.3 - 7.4
HE A T IN G ----- 7.4 - 7.6
IN PU T W AT T S (kW )
COOLIN G 1.53 - 1.60 1.55 - 1.62
HE A T IN G ----- 1.56 - 1.65
E E R (kW /kW )
COOLIN G 2.68 - 2.59 2.55 - 2.47
HE A T IN G ----- 3.11 - 3.00
M O IS TU R E R E M OVAL (R /hr) 2.0 2.0
AIR CIR CU LAT ION-Hi (m
3
/hr) COOL 510 - 510 COOL 510 - 510 HE A T 560 - 560
E LE CT R ICA L DA T A
COM PR E S S OR
Note : Always use a vacuum pump to purge the air.
Refrigerant for purging the air is not charged in the outdoor unit at the factory.
DIM E N S ION S
TY PE
Herm etic type, Perm anent split condenser,
2 pole, S ingle phas e, Induction m otor
CODE
80238235
220-240V 50Hz
R E FR IG E R AN T R 410A (g) 1,300
POW ER S OU R CE (V ) 220 - 240 220 - 240
HI-S PE E D (r.p.m .) 1,380 - 1,380 COOL 1,380 - 1,380 HE A T 1,480 - 1,480
IN DOOR U NIT
M E D-S PE ED (r.p.m.) 1,290 - 1,290 COOL 1,290 - 1,290 HE A T 1,320 - 1,320
LO-S PE ED (r.p.m .) 1,200 - 1,200 COOL 1,200 - 1,200 HE A T 1,180 - 1,180
QU IE T (r.p.m .) 1,120 - 1,120 COOL 1,120 - 1,120 HE A T 1,030 - 1,030
OU TDOOR U N IT (r.p.m.) 770 - 800 770 - 800
IN DOOR U NIT
H x W x D (m m )
260 x 815 x 175
OU TDOOR U N IT 535 x 695 x 250
FA N M OTOR
W E IG HT
IN DOOR U NIT
G R OS S / N E T (kg)
H x W x D (m m )
G R OS S / N E T (kg)
12 / 10
OU TDOOR U N IT 37 / 34

Fujitsu ASY14FSACW Specifications

General

Brand	Fujitsu
Model	ASY14FSACW
Category	Air Conditioner
Language	English
