Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
3 Remote Control Signal Receiver
4 Indicator Lamps (Fig. 3)
5 OPERATION Indicator Lamp (red)
6 TIMER Indicator Lamp (green)
●
If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See Page 13 Auto Restart).
7 SUPER QUIET Indicator Lamp (green)
8 SWING Indicator Lamp (orange)
9 Intake Grille (Fig. 4)
0 Air Filter
A Air Flow Direction Louver
B Right-Left Louver
(behind Air Flow Direction Louver)
C Drain Hose
D Power Supply Plug
E Power Supply Cord
F Air Cleaning Filter (optional)
Fig. 5 Outdoor Unit
G Intake Port
H Outlet Port
I Pipe Unit
J Drain port (bottom)
NAME OF PARTS
● Refer to the folded out page on the cover.
Fig. 6 Remote Controller
K SLEEP button
L MASTER CONTROL button
M SET TEMP./SET TIME buttons
( )
N Signal Transmitter
O TIME ADJUST button
P SET TIMER button
Q FAN CONTROL button
R START/STOP button
S SET button
T SWING button
U ACL button
(located inside battery compartment)
Rear Side (Fig.7)
V TEST RUN button
● Touch the two metal contacts with a me-
tallic object to send the signal to perform
a test run.
● Perform a test run only when installing the
air conditioner. If the signal to perform a
test run is received during normal opera-
tion, the air conditioner’s thermostat will
malfunction.
● If the signal to perform a test run is re-
ceived during normal operation, the unit
will switch to the test operation mode and
the indoor unit’s OPERATION and TIMER
indicator lamps will flash simultaneously.
● To stop the test operation mode, press the
START/STOP button to stop the air condi-
tioner.
W Remote Controller Display (Fig. 8)
X Transmit Indicator
Y Operating Mode Display
Z Timer Mode Display
[ Fan Speed Display
\ Clook Display
] Temperature Set Display
` Timer Set Indicator
a Temperature Set Indicator
