Fujitsu ASY18TBA-W User Manual

– 1 –
SPECIFICATIONS
TYPE COOL & HEAT COOL COOL & HEAT COOL & HEAT
INDOOR UNIT
ASY18TBA-W ASY24EBA3W ASY24TBA-W ASY30TBA-W
ASG18TBA-W ASG24EBA3W ASG24TBA-W ASG30TBA-W
OUTDOOR UNIT
AOY18TNAL AOY24EPA3L AOY24TMAL AOY30TMAL
AOG18TNAL AOG24EPA3L AOG24TMAL AOG30TMAL
COOLING CAPACITY
(kW)
5.35 6.70 - 6.90 6.80 7.70
HEATING CAPACITY 5.55 ----- 7.70 8.60
POWER SOURCE (V) 1 , 230 3 , 380 - 415 1 , 230 1 , 230
FREQUENCY (Hz) 50
RUNNING
(A)
COOLING 8.5 4.6 - 4.6 12.1 14.5
CURRENT
HEATING 8.1 ----- 12.8 15.4
INPUT
(kW)
COOLING 1.90 2.68 - 2.76 2.75 3.15
WATTS
HEATING 1.82 ----- 2.82 3.30
E.E.R. (kW/kW)
COOLING 2.82 2.50 - 2.50 2.47 2.44
HEATING 3.05 ----- 2.75 2.61
MOISTURE REMOVAL ( /hr) 2.0 2.5 3.5
AIR CIRCULATION-Hi (m
3
/hr) 900 1,000 1,100
ELECTRICAL DATA
COMPRESSOR
FAN MOTOR
DIMENSIONS
TYPE Hermetic type, Deposit electrode condenser, 2 poles, Single phase, Induction motor
CODE 4JS330DAA 8R32KE-TFD-501 NE44VNDMT NE52VNHMT
REFRIGERANT R407C (g) 1,700 1,600 2,300 2,500
POWER SOURCE (V) 1 , 230 1 , 220 - 240 1 , 230 1 , 230
TYPE MFA-30HTT
INDOOR
HI-SPEED ( r.p.m. ) 1,080 1,190 1,320
UNIT
MED-SPEED ( r.p.m. ) 940 1,030 1,220
LO-SPEED ( r.p.m. ) 810 900 1,030
OUTDOOR
TYPE MFB-30DFT
UNIT
( r.p.m. ) , 730
INDOOR UNIT H x W x D 320 x 1,120 x 220
OUTDOOR UNIT (mm) 700 x 900 x 350 900 x 900 x 350
WEIGHT
INDOOR UNIT GROSS / NET 22 / 16
OUTDOOR UNIT (kg) 76 / 68 73 / 65 77 / 69 92 / 80
REFRIGERANT CHARGE
PIPE LENGTH 7.5 m 10 m 15 m 20 m 25 m Additional
MODELS (25 ft) (33 ft) (49 ft) (66 ft) (82 ft) refrigerant
ASY18TBA-W 1,700 g 1,800 g 2,000 g 2,200 g
-----
40 g (1.41 oz) / 3.3 ft (1 m)
ASG18TBA-W (60.0 oz) (63.5 oz) (70.5 oz) (77.6 oz) (over 7.5 m)
ASY24EBA3W 1,600 g 1,650 g 1,750 g 1,850 g
-----
20 g (0.71 oz) / 3.3 ft (1 m)
FULL CHARGE ASG24EBA3W (56.4 oz) (58.2 oz) (61.7 oz) (65.3 oz) (over 7.5 m)
AMOUNT ASY24TBA-W 2,300 g 2,400 g 2,600 g 2,800 g
-----
40 g (1.41 oz) / 3.3 ft (1 m)
ASG24TBA-W (81.1 oz) (84.7 oz) (91.7 oz) (98.8 oz) (over 7.5 m)
ASY30TBA-W 2,500 g 2,600 g 2,800 g 3,000 g 3,200 g 40 g (1.41 oz) / 3.3 ft (1 m)
ASG30TBA-W (88.2 oz) (91.7 oz) (98.8 oz) (105.8 oz) (112.9 oz) (over 7.5 m)
2003.05.14
